Specialized Nitrogen Generator For Application Of Laboratory

Pressure swing Adsorption(PSA) gas separating technology , It has been applied in gas separation for several decades and has been widely used in China and even all over the world.

Place of Origin:	CHINA
Brand Name:	WSX
Model Number:	WPZN-3~5000

Inquiry

TECHNICAL

Nitrogen flow rate:	50 NL/h~2000NL/h
nitrogen purity (non oxygenation):	≥99.9995%
Nitrogen dew point:	≤-60℃
Dust content:	≤0.01μm

FEATURES

The equipment operates with low energy consumption, low cost, fast gas production, and high purity Easy to adjust;

Perfect process design, optimal usage effect;

Modular structural design, saving floor space;

Easy to operate, stable performance, and high degree of automation;

Reasonable internal structure design to improve the adsorption of carbon molecular sieves Efficiency;

Special airflow diffusion setting, high-speed impact of reduced diameter airflow,Extend the service life of carbon molecular sieves.

APPLICATIONS

Nitrogen is mainly used in research institutes and laboratories for various research and experimental purposes.

微信图片_202204121129572

微信图片_20250306095152

WORKING PRINCIPLE

When the air in the pressurized through the purification and drying, Base on Aerodynamics, nitrogen and oxygen in the air in the zeolite molecular sieve (ZMS) on the Pressure swing adsorption will performance of different diffusion rate through the adsorption of nitrogen. Oxygen in carbon molecular sieve on the surface of the diffusion rate is higher than nitrogen. When the adsorption was not in balance, oxygen was absorbed by carbon molecular sieve in large quantity, and nitrogen was concentrated and enriched in the gas phase to achieve separation of oxygen and nitrogen.
